商品の詳細:
お支払配送条件:
|
| 冷媒: | R404A/R22/R507/R407C | 輸出: | グローバル |
|---|---|---|---|
| アプリケーション: | 冷凍の部品 | 材料: | ブラス |
| パッキング: | 輸出カートン箱 | ||
| ハイライト: | 冷凍および空気調節用具および装置,danfossの拡張弁 |
||
TDE/TDEX TDEBX - R22 TDES - R404A/R507 TDEZ/TDEBZ - R407C
指定:
| 部分 数 |
モデルいいえ。 | はんだ 関係 |
わずか 容量 （kW） |
蒸発の温度:°C | |||||
| -30 | -20 | -10 | -5 | 0 | 5 | ||||
| 評価される容量（kW） | |||||||||
| TDE/TDEX及びTDEBX - R22 | |||||||||
| 068H7054 | TDEX4 | 1/2 x 7/8 | 14 | 6.4 | 8.5 | 10.8 | 12.1 | 13.5 | 14.8 |
| 068H7058 | TDEX6 | 1/2 x 7/8 | 21 | 9.6 | 12.6 | 16.2 | 18.1 | 20.1 | 22.1 |
| 068H8106 | TDEX8 | 5/8 x 7/8 | 28 | 17.8 | 20.7 | 24 | 25.8 | 27.6 | 29.5 |
| 068H8108 | TDEX11 | 5/8 x 7/8 | 38 | 21.9 | 26.5 | 31.8 | 34.6 | 37.4 | 40.4 |
| 068H8112 | TDEX12.5 | 5/8 x 7/8 | 44 | 24.2 | 29.7 | 36 | 39.3 | 42.7 | 46.3 |
| 068H8116 | TDEX16 | 5/8 x 1-1/8 | 56 | 29.3 | 36.7 | 45.2 | 49.7 | 54.3 | 59 |
| 068H8118 | TDEX16 | 7/8 x 1-1/8 | 56 | 29.3 | 36.7 | 45.2 | 49.7 | 54.3 | 59 |
| 068H7080 | TDEBX20# | 7/8 x 1-1/8 | 70 | 38.6 | 47.5 | 57.5 | 62.9 | 68.4 | 74 |
| 068H7086 | TDEBX30# | 1-1/8 x 1-3/8 | 106 | 52.7 | 67.2 | 83.5 | 92.5 | 102 | 110 |
| 068H7088 | TDEBX40# | 1-1/8 x 1-3/8 | 140 | 69 | 88.4 | 110 | 122 | 135 | 147 |
| DanfossモデルTDES - R404A/R507 | |||||||||
| 068H8750 | TDES4.4 | 1/2 x 7/8 | 15.3 | 7.8 | 10.2 | 12.9 | 14.3 | 15.6 | 16.9 |
| 068H8751 | TDES5.5 | 1/2 x 7/8 | 19.3 | 9.5 | 12.5 | 15.9 | 17.6 | 19.3 | 21.1 |
| 068H8752 | TDES8.0 | 5/8 x 7/8 | 28 | 16.8 | 20.4 | 24.3 | 26.3 | 28.3 | 30.2 |
| 068H8753 | TDES9.1 | 5/8 x 7/8 | 32 | 18.7 | 23 | 27.6 | 30 | 32.3 | 34.4 |
| 068H8754 | TDES11.7 | 7/8 x 1-1/8 | 41 | 22.7 | 28.4 | 34.6 | 37.8 | 40.9 | 43.9 |
| 068H8755 | TDES13.9 | 7/8 x 1-1/8 | 49 | 26.5 | 33.4 | 40.8 | 44.4 | 48.8 | 52 |
| 068H8756 | TDES14.6 | 7/8 x 1-1/8 | 51 | 29.6 | 35.4 | 43.8 | 47.6 | 51.3 | 55 |
| 068H8757 | TDES19.0 | 7/8 x 1-3/8 | 66 | 36.8 | 46.1 | 56.2 | 61.3 | 66.5 | 71.4 |
| 068H8758 | TDES22.0 | 7/8 x 1-3/8 | 75 | 40.4 | 51.4 | 63.3 | 69.5 | 75.7 | 81.7 |
| 068H8759 | TDES29.0 | 7/8 x 1-3/8 | 101 | 53.7 | 68.6 | 84.9 | 93.3 | 101.4 | 110 |
| DanfossモデルTDEZ/TDEBZ - R407C | |||||||||
| 068H7004 | TDEZ4 | 1/2 x 7/8 | 14 | 6.2 | 8.4 | 10.8 | 12.2 | 13.5 | 14.9 |
| 068H7008 | TDEZ6 | 1/2 x 7/8 | 21 | 9.3 | 12.5 | 16.2 | 18.2 | 20.2 | 22.3 |
| 068H8260 | TDEZ8 | 5/8 x 7/8 | 28 | 17.5 | 20.6 | 24.1 | 25.9 | 27.8 | 29.7 |
| 068H8264 | TDEZ11 | 5/8 x 1-1/8 | 38.5 | 21.5 | 26.3 | 31.8 | 34.7 | 37.7 | 40.7 |
| 068H8268 | TDEZ12.5 | 5/8 x 1-1/8 | 44 | 23.8 | 29.5 | 36.1 | 39.5 | 42.9 | 46.5 |
| 068H8272 | TDEZ16 | 7/8 x 1-1/8 | 56 | 28.7 | 36.4 | 45.2 | 49.8 | 54.6 | 59.4 |
| 068H7030 | TDEBZ20# | 7/8 x 1-1/8 | 70 | 37.9 | 47.1 | 57.5 | 63.1 | 68.8 | 74.6 |
| 068H7032 | TDEBZ26# | 7/8 x 1-3/8 | 91 | 46.6 | 59.2 | 73.4 | 81 | 88.8 | 96.7 |
| 068H7036 | TDEBZ30# | 7/8 x 1-3/8 | 105 | 51.5 | 66.4 | 83.5 | 92.7 | 102 | 112 |
| 068H7038 | TDEBZ40# | 7/8 x 1-3/8 | 140 | 67.4 | 87.4 | 110 | 122 | 135 | 148 |
